- Enterprise-class universal docking for 2018 T, L, X, and X1 Series ThinkPad notebooks
- Innovative side connector minimizes desk space
- 1 x HDMI, 2x Display Port, 1 x VGA port, 2x USB-C Ports, 4x USB 3.1 Ports
- Intel vPro, PXE boot, Wake-on LAN, and MAC address pass-through
- Supports ThinkPad RapidCharge
- Mirrored power button and mechanical unlock
- Optional master key lock |
Overview
|
Product Name: |
Lenovo ThinkPad Ultra Docking Station 40AJ0135UK HDMiI USB C/3.1 VGA DP |
|
Product Code: |
40AJ0135UK |
| Pack Size: |
1 |
| Condition: |
As New
|
| Warranty: |
yes 12 Months |
|
Despatch Time: |
Usually ships same working day* |
|
Availability:
|
SOLD OUT |
| Category: |
Laptop Stands |
We Also Recommend These Products:
only £144.99
only £199.99
See More Below:
Description
The ThinkPad Ultra Docking Station provides the best docking experience for large enterprise ThinkPad customers. The innovative side connector, designed exclusively for ThinkPad notebooks, provides a driver-free way to connect conveniently and securely to a range of USB accessories and external displays. Its rapid charging support and mirrored power button make it easy to unlock and go.
The ThinkPad Ultra Docking Station is built for today's demanding office work, too, delivering 10 Gbps data transfer through four USB 3.1 ports. Connect up to three UHD displays for maximum productivity gains. Designed for enterprise environments, ThinkPad Ultra Docking Stations support PXE book, wake on LAN, and MAC address pass-through, simplifying asset management for IT managers. Painstakingly designed and extensively tested, ThinkPad Ultra Docks provide seamless docking in a minimized form factor.
Tech Specs
| |
|
|
Color
|
Black
|
|
Max Number of External Monitors
|
3
|
|
Weight
|
0.81 kg (1.79 lbs)
|
|
Refresh Rate
|
DisplayPort: 4096 x 2160 @ 60 Hz; DisplayPort or HDMI: 4096 x 2160 @ 60 Hz; VGA: 2048 x 1536 @ 85 Hz;; inchMaximum resolutioninch refers to what can be supported by the dock. Actual resolution will vary by laptop.
|
|
AC Plug
|
UK Standard Plug Type G
|
|
Hardware Requirements
|
ThinkPad Side Docking Connector
|
|
Warranty
|
CRU
|
|
Output Power
|
65 W
|
|
Brand
|
ThinkPad
|
|
OS Requirements
|
Windows 10
|
|
Agency Approvals
|
AS/NZS S-DOC, BSMI, CB, CE, EAC, EU DOC, FCC, ICES, KCC, NOM, Ukr SEPRO, UL/cUL, VCCI
|
|
Audio Ports
|
1 x 3.5 mm Stereo/Mic Combo Port
|
|
Charging Port
|
ThinkPad Slim-tip Port
|
|
USB Ports
|
2 x USB-C (10 Gbps, 5V/3A power); 4 x USB 3.1 Gen 2 (10 Gbps, 1 always-on)
|
|
Video Ports
|
2 x DisplayPort 1.4; 1 x HDMI 2.0; 1 x VGA
|
|
Package Type
|
Brown box
|
| |
|
|
Maximum Operating Temperature
|
35 degrees Celsius (95 degrees Fahrenheit)
|
|
Minimum Operating Temperature
|
0 degrees Celsius (32 degrees Fahrenheit)
|
|
Driver Needed
|
Preloaded in select ThinkPad laptops
|
|
Input Power
|
135 W
|
|
Power Button
|
Yes
|
|
Shipment Group
|
ThinkPad Ultra Docking Station; ThinkPad Slim-tip 135 W AC power adapter; Power cord; 2 keys; Product information, safety and warranty poster
|
|
Compatibility
|
P52s, L580, L480, T580, P580p, T480s, T480, X1 Carbon Gen 6, X280
|
|
Supported Operating Systems
|
OS Independent
|
Box Contents
- ThinkPad Ultra Docking Station (with key lock and 2 keys)
- ThinkPad Slim Tip 135 W Power Adapter and Power Cord
