- Extremely compact and lightweight design
- 1 Transmitter/1 Receiver (1x1:1) antenna configuration
- Compliant with IEEE 802.11n standard, with transfer rates up to 150Mbps
- Backward compatible with IEEE 802.11b/g standards, for up to 11/54Mbps connections respectively
- Supports security features such as WEP (64-128-bit), WPA and WPA2
- Broadcast distances up to 100m indoors and 300m outdoors
- Wi-Fi Protected Setup (WPS) push button or software configuration
- Infrastructure and Ad-Hoc network modes support |
Overview
|
Product Name: |
StarTech USB 150Mbps Mini Wireless Network Adapter 802.11n/g USB WiFi Adapter |
|
Product Code: |
usb150wn1x1w |
| Pack Size: |
1 |
| Condition: |
Brand New
|
| Warranty: |
Yes: 12 months |
|
Despatch Time: |
Usually ships same working day* |
|
Availability:
|
IN STOCK |
| Category: |
USB Adaptors - Wireless |
Description
Add high-speed Wireless-N connectivity to a desktop or laptop system through USB. The USB150WN1X1W USB Wireless Network Adapter lets you add high-speed Wireless-N connectivity to a desktop or laptop system through USB.
Using a 1T1R (1 Transmitter/1 Receiver) design over the 2.4GHz frequency, the USB WiFi adapter is capable of data transfer rates up to 150Mbps over an 802.11n network. The adapter uses a small form factor design that makes it conveniently portable and unobtrusive, when connected to a computer - it can even be left connected your laptop when in a carrying bag, without worry of damaging the adapter or the host port.
Backward compatible with 802.11b/g networks (11/54Mbps), this USB wireless adapter is a versatile wireless networking solution, offering support for security options such as WEP, WPA or WPA2, as well as wireless Quality of Service (QoS) support and quick device connection through Wireless Protected Setup (WPS).
Â
Specification
|
StarTech.com USB 150Mbps Mini Wireless N Network Adapter - 802.11n/g 1T1R USB WiFi Adapter - White USB Wireless Adapter - Wireless NIC (USB150WN1X1W) - network adapter - USB 2.0
|
|
Device Type
|
Network adapter
|
|
Form Factor
|
External
|
|
Interface (Bus) Type
|
USB 2.0
|
|
Dimensions (WxDxH)
|
1.5 cm x 1.9 cm x 0.7 cm
|
|
Weight
|
9 g
|
|
Data Link Protocol
|
802.11b/g/n
|
|
Data Transfer Rate
|
150 Mbps
|
|
Frequency Band
|
2.4 GHz
|
|
Compliant Standards
|
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
|
|
Colour
|
White
|
|
System Requirements
|
Microsoft Windows Server 2003, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows XP / Vista / 7 / 8 / 8.1 / 10, Microsoft Windows Server 2016, Apple MacOS X 10.5 - 10.14, Linux 2.6.x - 3.5, Linux 4.4.x - 4.11.x LTS versions only
|
|
Â
|
Â
|
Extended Specification
|
General
|
|
Device Type
|
Network adapter
|
|
Form Factor
|
External
|
|
Interface (Bus) Type
|
USB 2.0
|
Â
|
Aerial
|
|
Antenna
|
Internal
|
|
Antenna Qty
|
1
|
Â
|
Dimensions & Weight
|
|
Depth
|
1.9 cm
|
|
Height
|
0.7 cm
|
|
Weight
|
9 g
|
|
Width
|
1.5 cm
|
Â
|
Environmental Parameters
|
|
Humidity Range Operating
|
10 - 90%
|
|
Max Operating Temperature
|
40 °C
|
|
Min Operating Temperature
|
0 °C
|
Â
|
Miscellaneous
|
|
Colour
|
White
|
|
Encryption Algorithm
|
AES, TKIP, WPA, WEP
|
Â
|
Networking
|
|
Compliant Standards
|
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
|
|
Connectivity Technology
|
Wireless
|
|
Data Link Protocol
|
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
|
|
Data Transfer Rate
|
150 Mbps
|
|
Features
|
Full duplex mode, Quality of Service (QoS), Wi-Fi Protected Setup (WPS), 1T1R MIMO technology
|
|
Frequency Band
|
2.4 GHz
|
Â
|
Software / System Requirements
|
|
OS Required
|
Microsoft Windows Server 2003, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows XP / Vista / 7 / 8 / 8.1 / 10, Microsoft Windows Server 2016, Apple MacOS X 10.5 - 10.14, Linux 2.6.x - 3.5, Linux 4.4.x - 4.11.x LTS versions only
|
|
Â
|
Â
|
Box Contents
- StarTech USB Wifi Adapter
